T pressure tanks

Technical details.

Discuss specifications and the right configuration for your application with the Cellar Technician team.

Suitable for storing and fermenting sparkling wine.

Made of AISI 304 (W.Nr.1.4301/IIId) or AISI 316 (W.Nr.1.4404/IIId) stainless steel, with sheet thickness selected to ensure tank stability.

Suitable for fermentation under pressure and subject to PED certification requirements for pressure vessels.

60 mm expanded polyurethane insulation, clad in welded stainless steel sheet rather than riveted cladding.

Automatic TIG welding in an inert atmosphere, followed by pickling and brushing of the welds. Carefully polished internal surfaces reduce residue accumulation and make cleaning easier.

Mounted on legs with adjustable feet and thick base plates.

Tank dimensions, accessories and accessory positions are tailored to requirements.

Detailed technical drawings are submitted to the customer for approval before manufacture.

The range description specifies cooling jackets and PED/TUV certification.
